Air Conditioning System F7 F8 F9 Synthetic Bag Air Filter Media Rolls 0.5um

Product Categories
Sichuan Huajie Purification Equipment Co., Ltd.
Contact Now

Air Conditioning System F7 F8 F9 Synthetic Bag Air Filter Media Rolls 0.5um

  • 1
  • 2
  • 3

Place of Origin : Sichuan, China

Brand Name : TRAIRF

Packaging Details : 1. FCL Shipment Order, using 5 layers carton case
2. LCL Shipment order, using wooden case package outside
3.Customization

Supply Ability : 10000 Set/Sets per Month Air Conditioning Dust Collector Air Filter Bag F9

MOQ : 50 sets

Price : $9.00/sets 50-199 sets

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Delivery Time : 2-30days

Applicable Industries : Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising C

Porosity : 0.5um

Filter Media : Synthetic fiber

Airflow : 1000-3200CMB/ H

Dust Holding Capacity : 200-2400 g/㎡

Initial Pressure : 50 Pa

Work Temperature : 80 ℃

Application : Air conditioning system

Port : Shenzhen,Shanghai

Contact Now

F5 F6 F7 F8 F9 Synthetic Bag Air Filter Media Rolls



Description:

TRAIRF®F5 F6 F7 F8 F9 Synthetic Bag Air Filter Media Rolls is an extended surface air filter designed for most medium and high efficiency air filtration systems.This broad spectrum of styles and models make the main pack extremely versatile and suitable for almost any commercial or industrial air handling systems.



Product Details

1.Style

Filter Bag/Pocket Filter

2.Feature

Dust collector, Long Service Life

3.Material

Synthetic fiber,meltblown

4.Size

Customization is available

5.Color

White,Orange,Green,Pink,Yellow,Black

6.Frame

Galvanized,Aluminum alloy,Plastic box

7.Is used to

Air Conditioing system,air handling unit

8.Efficiency

35%-95%,G3,G4,F5-F8

10.Packing

Carton

11.Weight

Based on size&material

Purchase information

12.Minimum order

20 pcs

13.Sample time

3-5 working days

14.Lead time

15-25 days after payment

15.Payment

T/T

16.certificate

ISO9001 ,CE



SPECIFICAITONS:

Class Size H*W*D(mm) Bags Filtration area Rated air flow(m³/h) Initial resistance(Pa)  Recommend final resistance
35%(G4) 287*592*550 3 1.86 1700 15 350
592*592*550 5 3.12 3400 20
592*592*600 6 3.78 3400 20
45%(F5) 287*592*550 3 2.12 1700 20 400
592*592*550 5 3.66 3400 30
592*592*600 6 4.40 3400 30
65%(F6) 287*592*550 5 2.12 1700 45 400
592*592*550 5 3.66 3400 80
592*592*600 6 4.40 3400 80
85%(F7) 287*592*550 3 2.80 1700 100 400
592*592*550 5 4.78 3400 125
592*592*600 6 5.78 3400 125
95%(F8) 287*592*550 3 2.80 1700 110 450
592*592*550 5 4.78 1700 110
592*592*600 6 5.78 3400 130

*CUSTOMIZATION IS AVAILABLE



TRAIRF® F5 F6 F7 F8 F9 Synthetic Bag Air Filter Media Rolls  are widely used in ventilation and air conditioner system of laboratory, pharmacy, microelectronic, hospital, food industry etc which areas requesting a higher degree of air cleanliness.



Media:

Fiberglass and Synthetic Fiber filter media are available for TRAIRF® Air Filter Bag. Synthetic fiber media consist of one layer of spun bound on each side for strength and stability, one coarse fiber melt-blown layer for filtration of larger particles and one fine melt-blown layer for filtration of smaller particles.This media is extremely durable and non-shedding. Using a variety of materials, the range of filtration efficiency can be spanned from 45-50% to 90-95% and > 95%.
